ADC - .NET Despeckle, Deskew, Auto Crop, Clean Document Images with .NET

Document and Image Cleanup Algorithms

DotImage Advanced Document Cleanup (ADC) is included with DotImage Document Imaging, providing document cleanup algorithms that can be applied to scanned documents to clean them up for better compression and archival, increased readability, and pre-OCR processing.

ADC Overview

DotImage ADC uses proprietary algorithms developed by our research and development team that are designed to automatically select the best parameters to apply for fast and accurate processing.  The commands included in ADC extend the command interfaces in DotImage and can easily be applied to an existing application built with DotImage.  See the online Document Cleanup Demo that demonstrates ADC with our AJAX-enabled Web Image Viewer.

Feature List

The following commands are available and most can be applied onto the entire image, or a region of interest:

Binarize

Uses a choice of three thresholding methods (adaptive, global, or simple) to efficiently and accurately convert a color or grayscale image to binary.  Binarize often results in better bi-tonal documents than scanning directly to black and white.

Binarize Orig Binarize Processed

Advanced Border Removal

Automatically removes black borders from a bi-tonal image using a sophisticated object detection algorithm.  Scanning documents often results in an unnecessary border around the image.

BorderRemoval Original BorderRemoval Processed

Margin Crop

Removes margins (whitespace) from each side of an image.  Useful for decreasing image size, and isolating relevant features on an image for processing.

Auto Border Crop

Similar to Advanced Border Removal, but crops the border as opposed to removing the feature.  Uses a higher speed algorithm than Advanced Border Removal.

Speck Removal

Removes specks of a specified size from a bi-tonal image.  Useful for removing noise from an image introduced by a scanner or when thresholding from a color or grayscale image.

Speck Removal Original Speck Removal Processed

Hole Punch Removal

Detects and removes hole punch artifacts from a bi-tonal image.  Will automatically remove round hole punches from bi-tonal images from any of the 4 sides that appear when these documents are scanned.

Hole Punch Removal Original Hole Punch Removal Processed

Blob Removal

Removes arbitrary blobs of a specified size from a bi-tonal image.

Blank Page Detection

Automatically detects if a bi-tonal document is blank using a sophisticated object detection algorithm.  Useful when scanning duplex (both sides) when the back side of the document is blank.

Automatic Page Inversion

Automatically detects and optionally inverts an image when the background is black and the foreground is white.  Useful when a scanner mistakenly inverts image data, or if the image was saved with incorrect tags resulting in inverted data.

Automatic Text Inversion

Detects inverted text regions in a bi-tonal image and automatically inverts them so that OCR engines can recognize the text.

Auto Text Inversion Original Auto Text Inversion Processed

Line Removal

Automatically removes horizontal or vertical lines from a bi-tonal image and reconnects broken characters.  Useful for pre-processing a form prior to OCR.

Line Removal Original Line Removal Processed

Halftone Removal

Detects and removes shaded regions in a bitonal image, created when thresholding color or gray images to bitonal with shaded image areas. Often referred to as "Dot Shade Removal".

Halftone Removal Original Halftone Removal Processed

Auto Deskew

Detects skew in a bi-tonal document and corrects the image by rotating it.  Useful for deskewing scanned documents.  Note: this command is included in DotImage Document Imaging without the need to purchase ADC.

Deskew Original Deskew Processed



How-to


All of the commands in the Advanced Document Cleanup module can be used in the same basic manner:

BinarizeCommand
myBinarizeCommand = new BinarizeCommand();
ImageResults results = myBinarizeCommand.Apply(myOriginalImage);
AtalaImage myNewImage = results.Image;

The commands work best on images that have a 1-bpp pixel format.  See these articles for more ways to use the ADC commands:

Deskewing a Color Image
How to Apply the AutoBorderCropCommand to a non 1-bpp image
Creating a Custom ImageCommand
Cleaning Document Images on the Web with AJAX
